Calibration of an FDR soil moisture sensor accounting for organic matter and andic properties in Jeju volcanic ash soils
Chol Jun Yang1†
,
Hosung Lee2†
,
Won-Pyo Park3*
1Researcher, Jeju Special Self-Governing Province Agricultural Research & Extension Service, Jeju 63556, Korea
2Master Student, Plant Resources and Environment Major, College of Applied Life Science, SARI, Jeju National University, Jeju 63243, Korea
3Associate Professor, Plant Resources and Environment Major, College of Applied Life Science, SARI, Jeju National University, Jeju 63243, Korea
*Corresponding Author
†These authors contributed equally to this work.
31 May 2026. pp. 172-183
PDF XML Citation
Abstract

Dielectric sensors are calibrated using soils of various types, but default factory calibration functions may not be valid under all conditions. Soils with high soil organic matter (SOM) content and volcanic ash soils often require soil-specific calibration to achieve acceptable accuracy. This study was aimed to developed and evaluated practical calibration methods for the TEROS 12 FDR (frequency domain reflectometry) soil moisture sensor using 39 soil samples from Jeju Island, covering a wide range of SOM (10 - 300 g kg-1) and contrasting andic properties. During controlled drying of repacked soils in containers at field bulk density, raw sensor counts were measured twice daily and paired with gravimetrically determined reference volumetric water content (θref). We compared the factory calibration equation (FCE) with the OM-group (OMCE) and integrated (ICE) calibration equations using bias and soil-level RMSE. The FCE exhibited moisture-dependent bias, overestimating θref under dry conditions and underestimating at medium to high moisture, with greater variability in high SOM soils and Andisols. Across all soils, RMSE decreased from 0.067 m3 m-3 (FCE) to 0.048 m3 m-3 (OMCE; 28.0% reduction) and 0.047 m3 m-3 (ICE; 29.8% reduction). OMCE performed best at low moisture, whereas ICE most effectively reduced errors in Andisols under high moisture. In Jeju volcanic soils, OMCE provides a practical option when SOM information is available, whereas ICE offers a robust general calibration for soils with mixed andic properties, improving the reliability of TEROS 12-based moisture monitoring.

OM-group and integrated calibration equations improved TEROS 12 soil moisture sensor accuracy in Jeju volcanic ash soils relative to the factory calibration.
Keywords
Andisols
Calibration equation
Sensor accuracy
Soil water sensor
Volumetric soil water content
References
1

Bircher S, Andreasen M, Vuollet J, Vehviläinen J, Rautiainen K, Jonard F, Weihermüller L, Zakharova E, Wigneron J-P, Kerr YH. 2016. Soil moisture sensor calibration for organic soil surface layers. Geosci Instrum Method Data Syst. 5:109-125. https://doi.org/10.5194/gi-5-109-2016

10.5194/gi-5-109-2016
2

Burt R. 2004. Soil Survey Laboratory Methods Manual. Soil Survey Investigations Report No. 42, Version 4.0. Natural Resources Conservation Service, USDA, Washington, DC, USA.

3

Fares A, Polyakov V, Swanson K. 2011. Improved calibration functions of three capacitance probes for the measurement of soil moisture in tropical soils. Sensors. 11:4858-4874. https://doi.org/10.3390/s110504858

10.3390/s11050485822163880PMC3231402
4

Fares A, Awal R, Bayabil HK. 2016. Soil water content sensor response to organic matter content under laboratory conditions. Sensors. 16:1239. https://doi.org/10.3390/s16081239

10.3390/s1608123927527185PMC5017404
5

Ferrarezi RS, Nogueira TAR, Zepeda SGC. 2020. Performance of soil moisture sensors in Florida sandy soils. Water. 12:358. https://doi.org/10.3390/w12020358

10.3390/w12020358
6

Huh YS, Kim EJ, Noh SJ, Jeon YM, Park SW, Yun GS, Kim TI, Kim YH. 2020. Characteristics of growth, yield, and physiological responses of small-sized watermelons to different soil moisture contents affected by irrigation starting point in a plastic greenhouse. Prot Hortic Plant Fact. 29:388-398. https://doi.org/10.12791/KSBEC.2020.29.4.388

10.12791/KSBEC.2020.29.4.388
7

Kassaye, KT, Boulange J, Saito H, Watanabe H. 2019. Calibration of capacitance sensor for Andosol under field and laboratory conditions in the temperate monsoon climate. Soil Tillage Res. 189:52-63. https://doi.org/10.1016/j.still.2018.12.020

10.1016/j.still.2018.12.020
8

Kim MS, Lee TG, Lee EJ, Jung HI, Lee SG. 2025. Effects of plowing depth on crops (watermelon, muskmelon, and squash) yield and soil chemical properties under plastic film house. Korean J Soil Sci Fert. 58:1-13. https://doi.org/10.7745/KJSSF.2025.58.1.001

10.7745/KJSSF.2025.58.1.001
9

Lee K, Kim JK, Lee J, Kim J. 2022. Comparisons of soil water retention characteristics and FDR sensor calibration of field soils in Korean orchards. J Bio-Environ Control. 31:401-408. https://doi.org/10.12791/KSBEC.2022.31.4.401

10.12791/KSBEC.2022.31.4.401
10

METER Group Inc. 2021. TEROS 11/12 User Manual. METER Group Inc.

10.1002/cprt.30980
11

Mizota C, van Reeuwijk LP. 1989. Clay Mineralogy and Chemistry of Soils Formed in Volcanic Material in Diverse Climatic Regions. Soil Monograph 2. ISRIC, Wageningen, Netherlands.

10.1016/0016-7061(88)90039-0
12

Moon KH, Kim SJ, Ko JH, Lee JH. 2011. Calibrating capacitance soil moisture sensors for determining water content in volcanic ash soils. Korean J Soil Sci Fert. 44:331-336. https://doi.org/10.7745/KJSSF.2011.44.3.331

10.7745/KJSSF.2011.44.3.331
13

Mosquera GM, Franklin M, Jan F, Rolando C, Lutz B, David W, Patricio C. 2021. A field, laboratory, and literature review evaluation of the water retention curve of volcanic ash soils: How well do standard laboratory methods reflect field conditions? Hydrological Processes. 35:e14011. https://doi.org/10.1002/hyp.14011

10.1002/hyp.14011
14

NAAS (National Academy of Agricultural Science). 2014. Taxonomical Classification of Korean Soil. RDA, Suwon, Korea.

15

NIAST (National Institute of Agricultural Science and Technology). 2000. Methods of Soil and Plant Analysis. NIAST, RDA, Suwon, Korea.

16

Park HS, Lee CY, Lee DG, Kang HJ, Oh HK, Lee JW. 2023. Effect of soil moisture conditions on growth and fruit characteristics of ‘Bokjo’ jujube (Ziziphus jujuba Mill.). Korean J Soil Sci Fert. 56:478-487. https://doi.org/10.7745/KJSSF.2023.56.4.478

10.7745/KJSSF.2023.56.4.478
17

Park MK, Ok JH, Kim DH, Lee SG, Son JW. 2025. Yield and water balance response of Italian ryegrass to different fertilizer application amount in weighable lysimeter. Korean J Soil Sci Fert. 58:643-54. https://doi.org/10.7745/KJSSF.2025.58.4.643

10.7745/KJSSF.2025.58.4.643
18

Park WP, Song KC, Koo BJ, Hyun HN. 2019. Distribution of available silicon of volcanic ash soils in Jeju Island. Appl Environ Soil Sci. 2019:Article ID 2729694. https://doi.org/10.1155/2019/2729694

10.1155/2019/2729694
19

Park WP, Koo BJ. 2020. Silicon and aluminum mobility in soils of Jeju Island, Korea. Appl Environ Soil Sci. 2020:Article ID 3905813. https://doi.org/10.1155/2020/3905813

10.1155/2020/3905813
20

Regalado CM, Carpena RM, Socorro AR, Moreno JH. 2003. Time domain reflectometry models as a tool to understand the dielectric response of volcanic soils. Geoderma. 117:313-330. https://doi.org/10.1016/S0016-7061(03)00131-9

10.1016/S0016-7061(03)00131-9
21

Robinson DA, Campbell CS, Hopmans JW, Hornbuckle BK, Jones SB, Knight R, Ogden F, Selker J, Wendroth O, et al. 2008. Soil moisture measurement for ecological and hydrological watershed-scale observatories: A review. Vadose Zone J. 7:358-389. https://doi.org/10.2136/vzj2007.0143

10.2136/vzj2007.0143
22

Seyfried MS, Murdock MD. 2004. Measurement of soil water content with a 50-MHz soil dielectric sensor. Soil Sci Soc Am J. 68:394-403. https://doi.org/10.2136/sssaj2004.3940

10.2136/sssaj2004.3940
23

Shoji S, Nanzyo M, Dahlgren RA. 1993. Volcanic Ash Soils: Genesis, Properties and Utilization. Developments in Soil Science 21. Elsevier, Amsterdam, Netherlands.

24

Soil Survey Staff. 2014. Keys to Soil Taxonomy. USDA-NRCS, Washington, DC.

25

Song KC, Yoo SH. 1994. Andic properties of major soils in Cheju Island. III. Conditions for formation of allophane. Korean J Soil Sci Fert. 27:149-157.

26

Tomer MD, Meek DW, Jaynes DB. 1999. A dielectric water content relationship for sandy volcanic soils in New Zealand. Soil Sci Soc Am J. 63:777-781. https://doi.org/10.2136/sssaj1999.634777x

10.2136/sssaj1999.634777x
27

Topp GC, Davis JL, Annan AP. 1980. Electromagnetic determination of soil water content: Measurements in coaxial transmission lines. Water Resour Res. 16:574-582. https://doi.org/10.1029/WR016i003p00574

10.1029/WR016i003p00574
